Pepperl+Fuchs Sensor Inductive NBB20-U1K-N0 123G1xxD 70133099 shielded NAMUR
Product type
Sensor
Contact type
1 breaker
Switching distance (max.)
20 mm
Outputs
NAMUR
Model
Inductive
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Use Duration: 20 A
- Hysteresis: 1... 15 type. 5%
- Product type
Sensor
- Type
NBB20-U1K-N0 123G1xxD
- Contact type
1 breaker
- Switching distance (max.)
20 mm
- Outputs
NAMUR
- Enclosure material
PA
- Model
Inductive
- Installation type
shielded
- Connector
Screw terminals
- Min. temperature
-25 °C
- Max. temperature
+100 °C
IP66
IP68
IP69K
- Content
1 pc(s)
- Switching frequency
250 Hz
Documents & Downloads
Datasheet
Datasheet 2131618 Pepperl+Fuchs Sensor Inductive NBB20-U1K-N0 123G1xxD 70133099 shielded NAMUR
User & Safety Instructions
User & Safety Instructions 2131618 Pepperl+Fuchs Sensor Inductive NBB20-U1K-N0 123G1xxD 70133099 shielded NAMUR
Conformity certificate
Conformity certificate 2131618 Pepperl+Fuchs Sensor Inductive NBB20-U1K-N0 123G1xxD 70133099 shielded NAMUR
Description
Switching distance: 20 mm, installation: flush, switching function: Normally-closed (NC), Output Type: NAMUR, nominal voltage: 8.2 V (Ri approx. 1 kΩ)
