Pepperl+Fuchs Sensor Inductive NBN50-L2K-A0-V1 316607-0011 M12 non-shielded NPN
Product type
Sensor
Max. operating voltage
30 V DC
Contact type
Antivalent
Switching distance (max.)
50 mm
Outputs
NPN
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Sensor
- Type
NBN50-L2K-A0-V1
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Contact type
Antivalent
- Switching distance (max.)
50 mm
- Outputs
NPN
- Enclosure material
Polyamide
- Model
Inductive
- Installation type
non-shielded
- Size
M12
- Connector
M12 plug (4-pin)
- Features
LED indicator
- Min. temperature
-25 °C
- Max. temperature
70 °C
IP68
IP69
- Content
1 pc(s)
- Wireless charging
No
- Switching frequency
40 Hz
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2628313 Pepperl+Fuchs Sensor Inductive NBN50-L2K-A0-V1 316607-0011 M12 non-shielded NPN
User & Safety Instructions
User & Safety Instructions 2628313 Pepperl+Fuchs Sensor Inductive NBN50-L2K-A0-V1 316607-0011 M12 non-shielded NPN
