Pepperl+Fuchs Sensor Inductive NBN8-18GK50-A2-10M 237200 M18 non-shielded PNP
Product type
Sensor
Max. operating voltage
30 V
Contact type
Antivalent
Switching distance (max.)
8 mm
Outputs
PNP
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Sensor
- Type
NBN8-18GK50-A2-10M
- Min. operating voltage
10 V
- Max. operating voltage
30 V
- Operating voltage
10 - 30 V
- Contact type
Antivalent
- Switching distance (max.)
8 mm
- Outputs
PNP
- Enclosure material
PBT
- Model
Inductive
- Installation type
non-shielded
- Size
M18
- Connector
Cable
- Cable length
10 m
- Features
LED indicator
- Min. temperature
-25 °C
- Max. temperature
70 °C
IP69K
- Content
1 pc(s)
- Wireless charging
No
- Switching frequency
500 Hz
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2627881 Pepperl+Fuchs Sensor Inductive NBN8-18GK50-A2-10M 237200 M18 non-shielded PNP
User & Safety Instructions
User & Safety Instructions 2627881 Pepperl+Fuchs Sensor Inductive NBN8-18GK50-A2-10M 237200 M18 non-shielded PNP
