Image similar
Pepperl+Fuchs Sensor Inductive NBN8-18GK50-E1-5M 199977 non-shielded NPN
Product type
Sensor
Max. operating voltage
30 V
Contact type
1 breaker
Switching distance (max.)
8 mm
Outputs
NPN
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Product type
Sensor
- Type
NBN8-18GK50-E1-5M
- Min. operating voltage
10 V
- Max. operating voltage
30 V
- Operating voltage
10 - 30 V
- Contact type
1 breaker
- Switching distance (max.)
8 mm
- Outputs
NPN
- Enclosure material
PBT
- Model
Inductive
- Installation type
non-shielded
- Connector
Cable
- Cable length
5 m
- Min. temperature
-25 °C
- Max. temperature
70 °C
IP67
- Content
1 pc(s)
- Wireless charging
No
- Switching frequency
500 Hz
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2627163 Pepperl+Fuchs Sensor Inductive NBN8-18GK50-E1-5M 199977 non-shielded NPN
User & Safety Instructions
User & Safety Instructions 2627163 Pepperl+Fuchs Sensor Inductive NBN8-18GK50-E1-5M 199977 non-shielded NPN
Description
Switching distance: 8 mm, installation: Non-flush, switching function: NC contact (NC), output type: NPN, operating voltage: 10 ... 30 V, operating current: 0 ... 100 mA, connection type 5 m, PVC cable
This text is machine translated.
This text is machine translated.
Features
- General dataSwitching function: NC contact (NC)Output type: NPNSwitching distance: 8 mmInstallation: Non-flushOutput polarity: DCSafe switching distance: 0 ... 6.48 mmReduction factor rAl: 0.45Reduction factor rCu: 0.3Reduction factor rV2A (1.4301) : 0.7Output type: 3-wireCharacteristicsOperating voltage 10 ... 30 VSwitching frequency: 0 ... 500 HzReverse polarity protection: Reverse polarity protectedShort-circuit protection: IsochronousVoltage drop ≤ 3 VOperating current: 0 ... 100 mAResidual current: 0 ... 0.5 mA type. 0.1 µA at 25 °C.No-load current ≤ 15 mASwitching status indicator: LED, yellowCompliance with standards and directivesCompliance Standards EN 60947-5-2:2007 | IEC 60947-5-2:2007Approvals and certificatesUL approval: CULus Listed, General PurposeCSA approved: CCSAus Listed, General PurposeCCC approval: Products with a maximum operating voltage of ≤36 V are not subject to approval and therefore do not have a CCC marking.Ambient conditionsAmbient temperature: -25 ... 70 °C (-13 ... 158 °F)Mechanical data:Wire cross-section 0.34 mm2Housing material: PBTFace: PBTProtection class IP67Note: Use only supplied nuts
