Pepperl+Fuchs Sensor Inductive NCB10-30GM40-N0-10M 123G1x3D 70133293 shielded NAMUR
Product type
Sensor
Switching distance (max.)
10 mm
Outputs
NAMUR
Model
Inductive
Connector
Cable
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Use Duration: 20 A
- Idling current: max. 25 mA at 24 V supply voltage.
- Hysteresis: 1... 15 type. 5%
- Product type
Sensor
- Type
NCB10-30GM40-N0-10M 123G1x3D
- Switching distance (max.)
10 mm
- Outputs
NAMUR
- Enclosure material
Stainless steel
- Model
Inductive
- Installation type
shielded
- Connector
Cable
- Cable length
10 m
- Min. temperature
-25 °C
- Max. temperature
+100 °C
IP67
- Content
1 pc(s)
- Switching frequency
200 Hz
Documents & Downloads
Datasheet
Datasheet 2131664 Pepperl+Fuchs Sensor Inductive NCB10-30GM40-N0-10M 123G1x3D 70133293 shielded NAMUR
User & Safety Instructions
User & Safety Instructions 2131664 Pepperl+Fuchs Sensor Inductive NCB10-30GM40-N0-10M 123G1x3D 70133293 shielded NAMUR
Conformity certificate
Conformity certificate 2131664 Pepperl+Fuchs Sensor Inductive NCB10-30GM40-N0-10M 123G1x3D 70133293 shielded NAMUR
Description
Switching distance: 10 mm, installation: flush, switching function: Normally-closed (NC), Output Type: NAMUR, Rated: 8 V
