Pepperl+Fuchs Sensor Inductive NCB4-12GM35-Z5 121008 M12 shielded Two-wire
Product type
Sensor
Max. operating voltage
30 V
Contact type
1 breaker
Switching distance (max.)
4 mm
Outputs
Two-wire
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Operating current:2-100 mA
- Product type
Sensor
- Type
NCB4-12GM35-Z5
- Min. operating voltage
3.5 V
- Max. operating voltage
30 V
- Operating voltage
3.5 - 30 V
- Contact type
1 breaker
- Switching distance (max.)
4 mm
- Outputs
Two-wire
- Enclosure material
Brass
- Model
Inductive
- Installation type
shielded
- Size
M12
- Connector
Cable
- Min. temperature
-25 °C
- Max. temperature
+70 °C
IP67
- Content
1 pc(s)
- Switching frequency
1000 Hz
Documents & Downloads
Datasheet
Datasheet 2129595 Pepperl+Fuchs Sensor Inductive NCB4-12GM35-Z5 121008 M12 shielded Two-wire
User & Safety Instructions
User & Safety Instructions 2129595 Pepperl+Fuchs Sensor Inductive NCB4-12GM35-Z5 121008 M12 shielded Two-wire
Conformity certificate
Conformity certificate 2129595 Pepperl+Fuchs Sensor Inductive NCB4-12GM35-Z5 121008 M12 shielded Two-wire
Description
Switching distance: 4 mm, installation: flush, switching function: Normally-closed (NC), Output Type: Two-wire, operating voltage: 3.5 ... 30V, operating current: 2... 100 mA
