Pepperl+Fuchs Sensor Inductive NMB8-30GM55-E2-FE 908456 M30 shielded PNP
EAN:
Part number:
Item no:
Product type
Sensor
Max. operating voltage
30 V
Contact type
1 maker
Switching distance (max.)
8 mm
Outputs
PNP
Datasheet (PDF)
Technical specifications
- Use Duration: 20 A
- Operating current: ≤ 200 mA
- Hysteresis: 3... 15 type. 10%
- Product type
Sensor
- Type
NMB8-30GM55-E2-FE
- Min. operating voltage
10 V
- Max. operating voltage
30 V
- Operating voltage
10 - 30 V
- Contact type
1 maker
- Switching distance (max.)
8 mm
- Outputs
PNP
- Enclosure material
Stainless steel
- Model
Inductive
- Installation type
shielded
- Size
M30
- Connector
Cable
- Min. temperature
-40 °C
- Max. temperature
+70 °C
IP69K
- Content
1 pc(s)
- Switching frequency
10 Hz
Documents & Downloads
Datasheet
Datasheet 2129904 Pepperl+Fuchs Sensor Inductive NMB8-30GM55-E2-FE 908456 M30 shielded PNP
User & Safety Instructions
User & Safety Instructions 2129904 Pepperl+Fuchs Sensor Inductive NMB8-30GM55-E2-FE 908456 M30 shielded PNP
Conformity certificate
Conformity certificate 2129904 Pepperl+Fuchs Sensor Inductive NMB8-30GM55-E2-FE 908456 M30 shielded PNP
Description
Switching distance: 8 mm, installation: flush, switching function: Normally open (NO), Output Type: PNP, operating voltage: 10... 30 V DC, operating current: ≤ 200 mA
