Pepperl+Fuchs Sensor Inductive SC2-N0-GN 123G1xxD 70132954 NAMUR
Product type
Sensor
Max. operating voltage
25 V
Contact type
1 breaker
Outputs
NAMUR
Model
Inductive
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Use Duration: 20 A
- Hysteresis: 0.11... 2 mm
- Product type
Sensor
- Type
SC2-N0-GN 123G1xxD
- Min. operating voltage
5 V
- Max. operating voltage
25 V
- Operating voltage
5 - 25 V
- Contact type
1 breaker
- Outputs
NAMUR
- Enclosure material
PBT
- Model
Inductive
- Connector
Cable
- Min. temperature
-25 °C
- Max. temperature
+100 °C
IP67
- Content
1 pc(s)
- Switching frequency
5000 Hz
Documents & Downloads
Datasheet
Datasheet 2132098 Pepperl+Fuchs Sensor Inductive SC2-N0-GN 123G1xxD 70132954 NAMUR
User & Safety Instructions
User & Safety Instructions 2132098 Pepperl+Fuchs Sensor Inductive SC2-N0-GN 123G1xxD 70132954 NAMUR
Conformity certificate
Conformity certificate 2132098 Pepperl+Fuchs Sensor Inductive SC2-N0-GN 123G1xxD 70132954 NAMUR
Description
Slot width: 2mm, switching function: Normally-closed (NC), Output Type: NAMUR, operating voltage: 5... 25 V, nominal voltage: 8.2 V (Ri approx. 1 kΩ)
