Pepperl+Fuchs Sensor Ultrasound M30 PNP UC2000-30GM-E6R2-V15 Piece
Packaging type
Piece
Product type
Sensor
Max. operating voltage
30 V DC
Outputs
PNP
Switching distance (max.)
2000 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Detection range 80 mm - 2000 mm
- Blind zone: 0 mm - 80 mm
- Setting range 120 mm - 2000 mm
- Standard plate 100 mm x 100 mm
- Converter frequency: Approx. 180 kHz
- Response delay: Minimum: 65 ms, factory setting: 195 ms
- LED green: Permanent: Power on, flashing: Standby mode or learning function object detected
- Yellow LED: Permanent: Switching state Switching output, flashing: Learning function
- LED red: Permanent: Temperature/program plug not plugged in, flashing: Malfunction or learning function object not detected
- No-load current ≤ 50 mA
- Storage temperature: -40 °C to +85 °C.
- Distance hysteresis: 1 % of the set switching distance (factory setting), programmable
- Interface type: RS 232, 9600 bps
- Synchronization frequency, common mode: Max. 30 Hz
- Rated operating current 200 mA, short-circuit/overload-proof
- Voltage drop: ≤ 2.5 V
- Reproducibility: ≤ 0.1% of the final value
- Converter: Epoxy resin/glass-shout ball mixture, foam polyurethane
- Weight 140 g
- Packaging type
Piece
- Product type
Sensor
- Type
UC2000-30GM-E6R2-V15
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Outputs
PNP
- Switching distance (max.)
2000 mm
- Model
Ultrasound
- Features
LED indicator
- Connector
M12 (5-pin)
- Size
M30
- Enclosure material
Stainless steel
PBT
- Contact type
1 PNP
IP65
- Min. temperature
-25 °C
- Max. temperature
+70 °C
- (Ø)
30 mm
- Dim
(Ø) 30 mm
- Switching frequency
≤ 2.5 Hz
- UKCA
yes
