PFERD TOOLS 68000057 DS 400 x 3,5 x 25,4 SGP Diamond cutting disc Diameter 400 mm Bore diameter 25.4 mm Brick, Reinforce
EAN:
Part number:
Item no:
Highlights & Details
PFERD TOOLS diamond cutting wheel DS 400x3.5x25.4 mm SGP for quick cutting of stone and concrete
- - Max. RPM 4800 RPM
- - Form: 1A1R / DS
- - Metric width: 3.2 mm
- - Ø hole: 25.4 mm
- - Abrasive: Diamond
- - ø Outer metric: 400 mm
- - Height, lining: 12 mm
Technical specifications
- Product type
Diamond cutting disc
- Thickness
3.5 mm
- Material suitability
Brick
Reinforced concrete
Stone
Concrete
- Bore Ø
25.4 mm
- Dim
(Ø) 400 mm
- (Ø)
400 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3772917 PFERD TOOLS 68000057 DS 400 x 3,5 x 25,4 SGP Diamond cutting disc Diameter 400 mm Bore diameter 25.4 mm Brick, Reinforce
Description
PFERD TOOL diamond cutting discs are manufactured in compliance with the highest quality and safety standards. They guarantee optimum separation results and enable economical processing of different materials, e.g. concrete, wash concrete, clinker, hard rock, granite or other abrasive construction materials. The product range offers the optimum tool for every machining task. Powerful tool with segmented edge for aggressive, quick cutting of hard materials with ultimate cutting power and outstanding service life. With laser-welded segments.
Benefits:
- High-quality diamond qualities.
- Good cutting and short separation times.
- Good cutting comfort and high efficiency.
Application recommendations:
- If possible, wet grinding should always be preferred to dry grinding. This reduces tool wear, thermal damage and dust exposure.
- Disconnect with little pressure to avoid tool overheating.
- Suitable for angle grinders of all power classes.
- The maximum working speed is 100 m/s.
Editable materials:
- Brick
- Reinforced concrete
- Soft stones
- Concrete
Processing tasks:
- Disconnect
Drive types:
- Joint separator
- Petrol separator
- Machining centers
- Table saw
Ordering Information:
- Customer-specific tool solutions are available on request.
This text is machine translated.
