Phoenix Contact 1071048 PCB terminal Number of pins 4 Green 75 pc(s) Tray
EAN:
Part number:
Item no:
Packaging type
Tray
Product type
PCB terminal
CS
5 mm
Pins per row
4
Number of pins
4
Datasheet (PDF)
Highlights & Details
PCB terminal
- Content 75 pc(s)
Technical specifications
- Type of connection PCB: Solder connection
- Pollution level: 2
- Over voltage category III
- Packaging type
Tray
- Type
SPTAF 1/ 4-5,0-EL-EX
- Product type
PCB terminal
- Features
for wave soldering
- CS
5 mm
- No. of rows
1
- Pins per row
4
- Number of pins
4
- Series
SPTA
- Connection
Push-in spring-loaded terminal
- Nominal current
16 A
- Nominal current - rounded value
16 A
- Cross section (inflexible) (max.)
1.5 mm²
- Connector orientation
At an angle (to the PCB)
- Factory colour
Green
- Manufacturer part #
1071048
- Content
75 pc(s)
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3562714 Phoenix Contact 1071048 PCB terminal Number of pins 4 Green 75 pc(s) Tray
User & Safety Instructions
User & Safety Instructions 3562714 Phoenix Contact 1071048 PCB terminal Number of pins 4 Green 75 pc(s) Tray
Description
PCB terminal, rated current: 16 A, nominal cross-section: 1.5 mm², number of rows: 1, number of pins per row: 4, family: SPTAF 1/..-EL-EX, pitch: 5 mm, connection type: Push-in spring connection, mounting: Shaft soldering, Connection direction of conductor/board: 45°, color: green, pin layout: linear pinning, pin length [P]: 2.6 mm, number of soldering pins per potential: 2, packaging type: tray.
