Phoenix Contact 1105710 GW PN/MODBUS 2E/4DB9 Data gateway RJ-45, D-SUB9 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Type of connection D-SUB-9-plug
- Tightening torque: 0.5 Nm ... 0.6 Nm
- Conductor cross-section flexible: 0.20 mm² ... 2.50 mm².
- Wire cross-section AWG: 24 ... 12
- Width 45 mm
- Height: 99 mm
- Depth: 115 mm
- Colour: grey
- Material housing PA 6.6
- Ambient conditions: Environmental conditions
- Protection class: IP20
- Ambient temperature (operation): -40 °C ... 70 °C
- Ambient temperature (storage/transport): -40 °C ... 80 °C
- Altitude: < 2000 meters
- Standards/regulations EN 55022, EN 55024
- Mounting type: Rail mounting
- Permissible air humidity (operation): 10 % ... 95% (no condensation)
- Conformity/Approvals: Conformity/approvals
- ATEX: DEMKO 18ATEX 2026X: II 3 G
- Ex ec IIC T4 GC
- IECEx: IECEx UL 18.0023X
- Ex ec IIC T4 GC
- UL, USA / Canada: Class I, div. 2, GROUPS A, B, C, D T4A
- Transfer length ≤ 1200 m
- Supply voltage range: 10.8 V DC ... 30 V DC (via COMBICON plug-in screw terminals)
- Permissible humidity (storage/transport): 5 % ... 95% (no condensation)
- Note for application: Only for industrial use
- Signal: Ethernet; PROFINET; Modbus
- Function: Function
- Electromagnetic compatibility: Conformity to EMC directive 2014/30/EU
- Interference radiation: Interference radiation
- Pollutant test: ISA-S71.04-1985 G3 Harsh Group A.
- IEC 61000-6-2:2005
- Supported protocols: PROFINET, Modbus ASCII/RTU/TCP
- Load resistance 120 Ω (configurable)
- Supply: Supply
- Vibration resistance according to EN 60068-2-6/IEC 60068-2-6:
- Shock according to EN 60068-2-27/IEC 60068-2-27:
- Typical current consumption 110 mA (24 V DC)
- Maximum power consumption 120 mA (24 V DC)
- Number of channels: 2
- Usage restriction: Use restriction
- EMC note: EMC: Class A product, see manufacturer's declaration in the download area
- UL, USA UL 61010-1
- CCCex Note: Use in hazardous areas is not permitted in China.
- Ex data: Ex data
- Management: Web-based management
- Number of connections: 4
- Electrical isolation: IEC UL 61010-1 (VCC // Ethernet)
- MTBF: 63.5 years (Telcordia standard, temperature : 25 °C, exposure: 50 %, environmental factor = 1.0);42.3 years (Telcordia standard, temperature : 40 °C, exposure: 50 %, environmental factor = 1.5)
- Serial transfer rate: 0.3 / 0.6 / 1.2 / 2.4 / 4.8 / 9.6 / 19.2 / 38.4 / 57.6 / 115.2 / 230.4 kBit/s.
- Test voltage Data interface/data interface 1.5 kVeff (50 Hz, 1 min.)
- Test voltage Data interface/supply: 1.5 kVeff (50 Hz, 1 min);1.5 kVeff
- Status and diagnostic indicators: LEDs: Status, ACT/LNK (Ethernet traffic)
- Web server: Yes
- Auxiliary protocols: ARP, DHCP (client), PING
- Data: RS-232: Data: RS-232
- Pin assignment: 3, 5, 7
- File format/coding: 5/6/7/8 data bits, 1/2 stop bit, parity None/Straight/Odd/Mark/Blank
- Data flow control/protocols: Software handshake, Xon/Xoff or hardware handshake RTS/CTS
- Data: RS-422: Data: RS-422
- Data: RS-485: Data: RS-485
- ModBus/TCP client: Modbus/TCP client
- Number of Modbus TCP clients: 96
- DATA: PROFINET, MODBUS TCP: DATA: PROFINET, MODBUS TCP
- Product type
Data gateway
- Interfaces
RJ-45
D-SUB9
- Type
GW PN/MODBUS 2E/4DB9
- Min. operating temperature
-40 °C
- Operating temperature
-40 °C (min)
- Dim
(W x H x D) 45 x 99 x 115 mm
- Max. current consumption
120 mA
- Height
99 mm
- Width
45 mm
- Manufacturer part #
1105710
- Type
Carry rail mounting
- Depth
115 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3564228 Phoenix Contact 1105710 GW PN/MODBUS 2E/4DB9 Data gateway RJ-45, D-SUB9 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3564228 Phoenix Contact 1105710 GW PN/MODBUS 2E/4DB9 Data gateway RJ-45, D-SUB9 1 pc(s)
Description
THE GW PN/MODBUS... Enables two-way communication between PROFINET and Modbus protocols. Includes two RJ45 ports and four D-SUB-9 ports.
