Phoenix Contact 1415187 MG-INC-M20-S67L-PTES-LG Membrane gland M20 M20 Polypropylene Light grey 20 pc(s)
EAN:
Part number:
Item no:
Product type
Membrane gland
External thread
M20
Size
M20
Material
Polypropylene
Outside Ø
20 mm
Datasheet (PDF)
Technical specifications
- Length without connection thread: 7 mm
- Diameter of connection thread 20 mm
- Hexagonal corner dimensions 34 mm
- Screw connection material: Polypropylene
- Material seal: TPE
- Diameter through hole 20 mm - 20.7 mm
- External diameter of the cable: 6 mm - 13 mm
- Product type
Membrane gland
- Outside Ø
20 mm
- Factory colour
Light grey
- External thread
M20
- Size
M20
- Thread length
8 mm
- Clamp Ø
6 mm
- Terminal Ø (max.)
13 mm
- Length
15 mm
IP67
IP66
- Min. temperature
-40 °C
- Max. temperature
+65 °C
- Material
Polypropylene
- Content
20 pc(s)
- Manufacturer part #
1415187
- Type
MG-INC-M20-S67L-PTES-LG
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2209209 Phoenix Contact 1415187 MG-INC-M20-S67L-PTES-LG Membrane gland M20 M20 Polypropylene Light grey 20 pc(s)
User & Safety Instructions
User & Safety Instructions 2209209 Phoenix Contact 1415187 MG-INC-M20-S67L-PTES-LG Membrane gland M20 M20 Polypropylene Light grey 20 pc(s)
Description
Screw connection, material Screw connection: Polypropylene, Application: Standard, cable outer diameter 6 mm ... 13 mm, shielding: no, connection thread: M20, color: Light gray
