Phoenix Contact 1440643 Sensor/actuator cable M12 Plug 15.00 m No. of pins (RJ): 8 1 pc(s)
EAN:
Part number:
Item no:
Product type
Sensor/actuator cable
Connector type
Plug
Connector standard
Sensor connector
Connection side A
RJ45 plug
Connection side B
M12 Speedcon
Technical specifications
- Type
VS-M12MSS-IP20-94F/15,0/10G
- Product type
Sensor/actuator cable
- Connector type
Plug
- Connector standard
Sensor connector
- Connection side A
RJ45 plug
- Connection side B
M12 Speedcon
- No. of pins
8
- Cable length
15.00 m
- Jacket material
PUR
- Nominal voltage
48 V AC
- Connection
Plug
- Factory colour
Grey
- Thread type connection side
M12
- Cable colour
Blue
- Coding
X
IP65
- Features
Shielded
- Min. temperature
-20 °C
- Manufacturer part #
1440643
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1832999 Phoenix Contact 1440643 Sensor/actuator cable M12 Plug 15.00 m No. of pins (RJ): 8 1 pc(s)
Description
Ethernet-CABLE VS-M 12 MSS #1440643
