Phoenix Contact 1524336 Sensor/actuator cable M12 Plug 15.00 m No. of pins (RJ): 4 1 pc(s)
EAN:
Part number:
Item no:
Product type
Sensor/actuator cable
Connector type
Plug
Connector standard
Sensor connector
No. of pins
4
Cable length
15.00 m
Technical specifications
- Type
SAC-4P-M12MSD/15,0-933
- Product type
Sensor/actuator cable
- Connector type
Plug
- Connector standard
Sensor connector
- No. of pins
4
- Cable length
15.00 m
- Jacket material
PVC
- Nominal voltage
48 V AC
- Connection
M12 plug
- Thread type connection side
M12
- Thread type (wiring and installation)
M12
- Cable colour
Green
- Coding
D
- Contact material
CuSn
- Contact surface
Ni/Au
IP65
- Features
Shielded
Halogen-free
- Min. temperature
-40 °C
- Max. temperature
70 °C
- Manufacturer part #
1524336
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1833473 Phoenix Contact 1524336 Sensor/actuator cable M12 Plug 15.00 m No. of pins (RJ): 4 1 pc(s)
Description
Phoenix 1524336. Cable length: 15m, plug: M12, Product Color: green
