Phoenix Contact 1792643 PCB connector Total number of pins 4 No. of rows 1 50 pc(s)
EAN:
Part number:
Item no:
Product type
PCB connector
Total no. of pins
4
CS
5.08 mm
Content
50 pc(s)
No. of rows
1
Datasheet (PDF)
Highlights & Details
PCB terminal strip
- No. of rows 1
- Content 50 pc(s)
Technical specifications
- Mounting type: Snap in
- Rated voltage: 320 V
- Dimensioning surge voltage: 4 kV
- Rated current In:12 A.
- Flammability class of insulation material according to UL94: V0
- Diameter connection pin 1.6 mm
- Pin contact type
- Connector design: Fixed connector
- Pollution level: 2
- Material of the contact coating: Tin
- Over voltage category III
- Tape type: Cardboard (for SMD)
- Product type
PCB connector
- Total no. of pins
4
- No. of rows
1
- CS
5.08 mm
- Factory colour
Black
- Case material
PA
- Manufacturer part #
1792643
- Content
50 pc(s)
- Max. temperature
105 °C
- Min. temperature
-40 °C
- Type
CC 2,5/ 4-GF-5,08-LR P26THR
- Number of pins
4
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3452648 Phoenix Contact 1792643 PCB connector Total number of pins 4 No. of rows 1 50 pc(s)
User & Safety Instructions
User & Safety Instructions 3452648 Phoenix Contact 1792643 PCB connector Total number of pins 4 No. of rows 1 50 pc(s)
Description
PCB baseboard, rated cross-section: 2.5 mm², Colour: Black, rated current: 12 4 A, rated voltage (III/2): 320 V, contact surface: Sn, contact type: Pen, number of potential: 4, number of rows: 2.5, number of connections: 5.08, product family: CC 1/.-GF-LR, grid dimension: 4 mm, mounting: THR-soldering / wave length, pin layout: Pins: 2.6 mm, number of solder pins per potential: 1, connector system: COMBICON MSTB 2.5, mating face direction: standard, locking: lock-and-release locking, mounting system: lock & release thread flange, packaging type: packed in cardboard
This text is machine translated.
