Phoenix Contact 1809610 Screw terminal Number of pins 18 50 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Screw terminal
CS
5.08 mm
Pins per row
18
Number of pins
18
Highlights & Details
Pcb CONNECTION TERM 1809610 50 PCS
- Content 50 pc(s)
Technical specifications
- Packaging type
Piece
- Type
SMKDS 3/18-5,08
- Product type
Screw terminal
- Features
+ extractor sleeve
- CS
5.08 mm
- Pins per row
18
- Number of pins
18
- Series
SMKDS
- Stripping length (max.)
8 mm
- Connection
Print
Soldering
- Nominal current
24 A
- Nominal current - rounded value
24 A
- Connector orientation
At an angle (to the PCB)
- Wire protection
Yes
- Manufacturer part #
1809610
- Content
50 pc(s)
- Nominal voltage
400 V
- Width
91.44 mm
- Height
22.50 mm
- Length
16 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1832814 Phoenix Contact 1809610 Screw terminal Number of pins 18 50 pc(s) Piece
Description
Well-known connection principle allows use worldwide. Low heat generation through high contact force. Allows the connection of two conductors. Angled connection enables the multi-row arrangement on the PCB. Integrated exam on protection prevents an incorrect plugging of the conductor below the pull-out sleeve. Lateral locking allows individual combination of different poles.
