Phoenix Contact 1844743 PCB connector Total number of pins 8 No. of rows 2 300 pc(s)
EAN:
Part number:
Item no:
Product type
PCB connector
Total no. of pins
8
CS
2.54 mm
Content
300 pc(s)
No. of rows
2
Datasheet (PDF)
Highlights & Details
PCB terminal strip
- No. of rows 2
- Content 300 pc(s)
Technical specifications
- Rated voltage: 160 V
- Dimensioning surge voltage: 2.5 kV
- Rated current In:6 A.
- Flammability class of insulation material according to UL94: V0
- Diameter connection pin 1.2 mm
- Pin contact type
- Connector design: Fixed connector
- Pollution level: 2
- Material of the contact coating: Gold
- Over voltage category III
- Product type
PCB connector
- Total no. of pins
8
- No. of rows
2
- CS
2.54 mm
- Factory colour
Black
- Case material
PA
- Manufacturer part #
1844743
- Content
300 pc(s)
- Max. temperature
100 °C
- Min. temperature
-40 °C
- Type
DMC 0,5/ 4-G1-2,54 P20THR R44
- Number of pins
8
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3452664 Phoenix Contact 1844743 PCB connector Total number of pins 8 No. of rows 2 300 pc(s)
User & Safety Instructions
User & Safety Instructions 3452664 Phoenix Contact 1844743 PCB connector Total number of pins 8 No. of rows 2 300 pc(s)
Description
PCB baseboard, rated cross-section: 0.5 mm², Colour: Black, rated current: 6 8 A, rated voltage (III/2): 160 V, contact surface: Au, contact type: Pin, number of potentials: 8, number of rows: 0.5, number of connections: 2.54, product family: DMC 2/..-G1-THR, grid dimension: 4 mm, mounting: THR-soldering / wave soldering, pin layout: 2 mm, number of solder pins per potential: 1, connector system: COMBICON DFMC 0.5, mating face: standard, locking: without, mounting method: without, packaging type: strap in 44 mm width, sample quantities under SAMPLE DMC... available
