Name: Phoenix Contact 2905364 PT-IQ-PTB-BE-UT Surge protection main unit 1 pc(s)
Brand: Phoenix Contact
SKU: 3579937

Image similar

Datasheet (PDF)

Unavailable

Sales and shipping:

Technical specifications

Product family: PLUGTRAB IQ
Design: Base element, mounting rail assembly
Number of poles: 1
Message Surge Protection Faulty: Telecommunication contact
Connection type: screw terminals.
M3 screw thread
Tightening torque 0.5 Nm
Conductor cross-section flexible: 0.2 mm² ... 2.5 mm².
Conductor cross-section rigid: 0.2 mm² ... 4 mm².
Wire cross-section AWG: 24 ... 12
Width 17.7 mm
Height: 91.1 mm
Depth: 51.5 mm (including mounting rail 7.5 mm)
Division unit 1 TE
Colour: Black (RAL 9005);gray (RAL 7042)
Flammability class according to UL 94 V-0
Material housing PA 6.6
Mechanical Data: Mechanical Data
Open side wall: No.
Rated current: Max. 130 mA (24 V DC);max. 160 mA (20 V DC)
Required maximum backup fuse: 500 mA (F)
Ambient conditions: Environmental conditions
Protection class: IP20
Ambient temperature (operation): -40 °C ... 70 °C
Ambient temperature (storage/transport): -40 °C ... 85 °C
Altitude: ≤ 4000 m (amsl)
Standards/regulations: GB/T 3836.8
Note: 2021
Mounting type: Rail: 35 mm
Insulation properties: Insulation properties
Overvoltage category II
Pollution level: 2
Permissible air humidity (operation): 5 % ... 95 %.
Operating voltage: 20 V DC ... 30 V DC
Supply: Status display / Remote message: Supply: Status display / Remote message
Number of connectable surge protection modules: Max. 10
max. Input voltage UM 35 V DC
Maximum switching voltage UM 60 V DC
