Phoenix Contact EEM-EM355 Digital rack-mount meter
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Ambient temperature (operation): -25 °C ... 55 °C
- Description of the input: Active opto-isolated
- Power consumption 3.5 VA (1 W)
- Protection class II (EN 50470-1)
- Withstand voltage 6 kV
- Product type
Digital rack-mount meter
- Reading type
Active power
- Type
EEM-EM355
IP51 (front)
IP20 (terminals)
- Dim
(L x W x H) 67 x 72 x 90 mm
- Width
72 mm
- Height
90 mm
- Length
67 mm
- Interfaces
RS485
- Interfaces
RS485
Documents & Downloads
Datasheet
Datasheet 2225736 Phoenix Contact EEM-EM355 Digital rack-mount meter
Datasheet 2225736 Phoenix Contact EEM-EM355 Digital rack-mount meter
User & Safety Instructions
User & Safety Instructions 2225736 Phoenix Contact EEM-EM355 Digital rack-mount meter
Description
Three-phase energy meter for active power measurement with current transformer measurement 1 A / 5 A in networks up to 500 V, with S0 output, with digital input and RS-485 interface, certified according to MID-guideline
