Phoenix Contact FOC-FDX20-PP-LCQ6-MM FO splice box Optical fiber
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Mounting rail splice box, without pigtails, for 12x LC duplex
- Protection class: IP20
- Connection type: Cable gland M20
- External diameter of the cable: 6 mm - 12 mm
- Material casing: Steel sheet
- Cable outlet: Top and bottom
- Amount of the cable outlet: 2
- Ambient temperature (operating): -40 °C - +85 °C.
- Ambient temperature (mounting): 0 °C - +50 °C.
- Cable type: For all common cable types
- Cable type: Glass fiber
- Transmission medium: Fiber optic cable
- Fiber: GOF
- Number of slots: 24
- Number of fibers: 24
- Product type
FO splice box
Optical fiber
- Factory colour
Grey
- Length
115 mm
- Height
130 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2208972 Phoenix Contact FOC-FDX20-PP-LCQ6-MM FO splice box Optical fiber
Datasheet 2208972 Phoenix Contact FOC-FDX20-PP-LCQ6-MM FO splice box Optical fiber
User & Safety Instructions
User & Safety Instructions 2208972 Phoenix Contact FOC-FDX20-PP-LCQ6-MM FO splice box Optical fiber
Description
Easy to install. Includes cable gland.
