Phoenix Contact PSR-MM30-2NO-2DO-24DC-SP 2702358 Safety switchgear No. of relay outputs: 2
Product type
Safety switchgear
No. of relay outputs
2
Operating voltage
24 V DC
Type
PSR-MM30-2NO-2DO-24DC-SP
Probe inputs
3
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Ambient temperature (operation): -40 °C ... 55 °C (observe derating)
- Protection class: IP20
- Contact design: 2 release current paths
- Output fuse 6 A GL/GG
- Mechanical life: 10x 10 6 operations
- Mounting position: Vertical or horizontal
- Mounting instructions: See derating curve
- Connection type: Push-in connection
- Wire stripping length: 8 mm
- Pollution level: 2
- Over voltage category III
- Operating height: ≤ 2000 m (above sea level)
- Number of digital inputs: 6
- Mounting type: Rail mounting
- Protection class Installation location minimum: IP54
- Material casing: PBT
- Housing color: Yellow
- Operating voltage display: 1 x green LED (PWR)
- Status display: 2x LED green (OUT1, OUT2)
- Pluggable: Yes
- Conductor cross-section rigid max. 1.5 mm²
- Conductor cross-section flexible max. 1.5 mm²
- Conductor cross-section AWG max. 16
- Type
PSR-MM30-2NO-2DO-24DC-SP
- Product type
Safety switchgear
- No. of relay outputs
2
- Probe inputs
3
- Outputs
2
- Operating voltage
24 V DC
- Dim
(L x W x H) 114.5 x 22.5 x 117.5 mm
- Weight
190.9 g
- Width
22.5 mm
- Height
117.5 mm
- Length
114.5 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2209833 Phoenix Contact PSR-MM30-2NO-2DO-24DC-SP 2702358 Safety switchgear No. of relay outputs: 2
Datasheet 2209833 Phoenix Contact PSR-MM30-2NO-2DO-24DC-SP 2702358 Safety switchgear No. of relay outputs: 2
User & Safety Instructions
User & Safety Instructions 2209833 Phoenix Contact PSR-MM30-2NO-2DO-24DC-SP 2702358 Safety switchgear No. of relay outputs: 2
Description
Two-channel speed and standstill monitors up to SIL 3, Cat. 4, PL e, 2 safe relay outputs, suitable for the connection of HTL, TTL or Sin/Cos encoders as well as proximity switches, pluggable spring-loaded terminal, width 22.5 mm
