Phoenix Contact SACB-8/16-L-PT SCO P 1412060 Sensor & actuator box (active) M12 splitter + plastic thread 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Sensor & actuator box (active)
No. of splitters
8-way
Type
SACB-8/16-L-PT SCO P
Trunk line
Yes
Technical specifications
- Packaging type
Piece
- Product type
Sensor & actuator box (active)
- Type
SACB-8/16-L-PT SCO P
- Trunk line
Yes
- No. of splitters
8-way
- Status indicator
LED
- Connection
M12 socket
- Width
54 mm
- Length
149 mm
- Max. power rating per slot
4 A
- Total current (direct supply)
8 A
- Max. temperature
80 °C
- Min. temperature
-25 °C
- Connector cross section (max.)
1 mm²
- Connector cross section (min.)
0.2 mm²
- Case material
Plastic
- Total no. of pins
5
- Weight
0 kg
- Manufacturer part #
1412060
- Content
1 pc(s)
- Number of pins
5
- Height
43 mm
- Power rating (total)
8 A
- Power rating per I/O
8 A
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1827750 Phoenix Contact SACB-8/16-L-PT SCO P 1412060 Sensor & actuator box (active) M12 splitter + plastic thread 1 pc(s) Piece
Description
Safe in the field thanks to the molded housing and high degrees of protection. Flexible, decentralised bundling of signals in a source line. Flexible: distribution box with connection cover for the pre-fabrication on site.
