Pichler Modellbau C6188 Petrol 4 stroke model aircraft engine 37.97 cm³ Electronic ignition
EAN:
Part number:
Item no:
Highlights & Details
4 stroke model aircraft engine petrol engine NGH GF 38
- Slim design, compact and powerful
- WALBRO carburetor (optimized for NGH GF-38)
- Cylinder parts (replaceable)
- High-quality ball bearing
- High-strength connecting rod, 2-way needle bearing
- Original RCEXL ignition ("the best")
- Spare parts/maintenance service
- Technical data
- Displacement = 37.97cc
- Bore = 39.0mm
- Hub = 31.8mm
- Speed range = 1800 -8000 rpm
- Compression ratio = 9:1
- Oil/petrol mixture = 1:35
- Spark plug = CM-6
- Weight of engine incl. sensor, carburetor and spark plug = 1310g
- Weight of ignition = 100g
- Carburetor Walbro Custom WT1022
- Propeller (recommended) = 18 x 10, 19 x 8, 19 x10, 20 x 8
Technical specifications
- Product type
4 stroke model aircraft engine
- Engine type
Petrol
- Engine displacement (cc)
37.97 cm³
- Weight
1310 g
- Recommended propeller size
18 x 10 inch
- Bore Ø
39.0 mm
- Rotational speed (max.)
8000 U/min
- Rotational speed (min.)
1800 U/min
- Rotational speed range
1800 - 8000 U/min
- Features
Electronic ignition
- Manufacturer part #
C6188
- Stroke
31.8 mm
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2251924 Pichler Modellbau C6188 Petrol 4 stroke model aircraft engine 37.97 cm³ Electronic ignition
Description
Two-stroke petrol engine for flight models with a take-off weight of approx. 6 to 10kg.
Narrow installation dimensions and low weight distinguish the NGH GF-38 petrol engine. Due to the carburetor placed on the rear side, the engine is also best suitable for installation under narrow engine hoods. The NGH GF-38 looks like a conventional glow-ignition engine at first glance, but was designed from the ground up as a petrol engine.]
This text is machine translated.
Narrow installation dimensions and low weight distinguish the NGH GF-38 petrol engine. Due to the carburetor placed on the rear side, the engine is also best suitable for installation under narrow engine hoods. The NGH GF-38 looks like a conventional glow-ignition engine at first glance, but was designed from the ground up as a petrol engine.]
This text is machine translated.
Scope of delivery
- NGH GF-38 engine
- Mounting material, small parts
- Electronic ignition 4.8 -8.4V
- Spark plug CM-6
- Exhaust manifold
- Instructions German/English, exploded view and spare parts list
