Pracht 9430209m LED wet room light LED (monochrome) Built-in LED 74 W Neutral white White
EAN:
Part number:
Item no:
Highlights & Details
Pracht LED wet room light 840, DALI APOLLO G2 #9430209m
- Power= 74 W
- Total luminous flux= 11600 lm
- Colour temperature= 4000 K
- Neutral white
Technical specifications
- Energy efficiency class of light source according to EU regulation 2019/2015: Not relevant
- Suitable for wall mounting: Yes
- Suitable for pendulum suspension: Yes
- Suitable for ceiling mounting: Yes
- Suitable for panel mounting: No.
- Suitable for mounting on the panel: Yes
- Suitable for light band configuration: No.
- Suitable for the number of bulbs: 2
- Housing material: Plastic
- Housing color: White
- Cover material: Plastic opal
- Voltage type AC/DC
- Nominal current: 0.36 mA
- With operating device: No.
- Removable operating device: Yes
- Dimmer 0-10 V: No
- Dimmer 1-10 V: No
- DALI-2 dimming: Yes
- DALI dimming: Yes
- Dimmer DMX: No
- Dimmer DSI: No.
- Dimmer potentiometer (built-in): No.
- Dimmer GPRS: No.
- Dimming LineSwitch: No.
- Dimmer manufacturer-specific: No.
- Mains voltage modulation dimming: No.
- Dimming Phase section: No.
- Dimming leading edge: No.
- Dimming programmable: No.
- Dim. RF: No.
- Dimming Sine Wave Reduction: No.
- Dimming Touch and Dim: No.
- Zigbee dimming: No.
- Dimming with push-button: No.
- Dimming depends on the operating device: No.
- Without dimmer function: No.
- Light distributor: Reflector
- Color consistency (McAdam ellipse): SDCM3
- Rated life L70/B50 at 25 °C: 245604 h
- Rated life L80/B10 at 25 °C: 124487 h
- Rated life L90/B10 at 25 °C: 59851 h
- Max. Number of lights circuit breaker B16: 11
- Max. Number of lamps line circuit breakers C16: 18
- Protection class (IP) IP65
- Protection class (NEMA): 13
- Impact strength: IK08
- Protection class: I
- Lamp with limited surface temperature "D-sign": Yes
- Rated ambient temperature according to IEC62722-2-1: -45..60°C.
- Suitable for emergency light: No.
- Filament testing according to IEC 60695-2-11:650°C - 30 s.
- Max. System power 74 W
- Light output 157 lm/W
- Rated light current according to IEC 62722-2-1: 11600 lm
- Colour temperature: 4000 K
- Flicker value PST LM: 1
- Color Rendering Index CRI: 80-89
- Strobe effect value SVM: 0.4
- Width 232 mm
- Height/depth 142 mm
- Length: 1260 mm
- Type of wiring: With through wiring
- Number of pins: 5
- Conductor cross-section: 1.5 mm²
- Photobiological safety according to EN 62471: RG1
- Glare limiter (UGR): 24
- Adjustable color temperature: No.
- Product type
LED wet room light
- No. of bulbs
2
- Bulb type
LED (monochrome)
Built-in LED
- Length
1260.00 mm
74 W
- Height
142.00 mm
- Width
232.00 mm
4000 K
- Colour
Neutral white
- Total luminous flux
11600 lm
- Light features
Dimmable
IP65
- Factory colour
White
- Material
Plastic
- Dim
(L x W x H) 1260.00 x 232.00 x 142.00 mm
n.rel.
- Colour rendering index
80-89
- Light bulb included
Yes
- Colour temperature (max.)
4000 K
- Colour temperature (min.)
4000 K
- Colour temperature range
4000 - 4000 K
- Rated luminous flux
11600 lm
- Protection class
I
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3156299 Pracht 9430209m LED wet room light LED (monochrome) Built-in LED 74 W Neutral white White
Description
The new generation of the proven APOLLO wet room reflector light in industrial design. Shapely barrel end-pieces made of PBT, newly designed. Easy one-man mounting of reflector through integrated plug-in device with direction sensors and captive, easy-to-close stainless steel clips. Casing closed on all sides made of white, glass fiber reinforced, flame resistant, largely acid and alkali-resistant polyester resin, protection class IP65. Reflector with integrated industrial LED PCBs can be swiveled by 120°, with practical snapping in 10° steps. Short, age-resistant silicone seals. Integrated long-life electronic industrial converter. Especially robust through thermal uncoupling of LED and converter. Feed-through wiring up to 5x2.5mm² + 2x1.5mm² possible. The permitted ambient temperature is reduced by 1°C per 2A load of the through-wiring Variable mounting distances thanks to the stainless steel GRAND CLAMP SYSTEM, suitable for ceiling and horizontal wall mounting, pendant and rail mounting with accessories possible.
