Name: PTR Hartmann PCB connector Total number of pins 12 Contact spacing: 3.81 mm 51550122025D 1 pc(s) Piece
Brand: PTR Hartmann
SKU: 3590094

A green electrical terminal block with five connection points, featuring screw terminals for wire attachment on each side.

'Technical drawing of mechanical component with dimensions: width 3.81, length 10.4, height 15.5. Sectional view shows internal details.'

1/2

Image similar

Product type

PCB connector

Connector type

PCB connector

3.81 mm

Total number of pins

Packaging type

Piece

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Content: 1 pc(s)
Total number of pins: 12

Our service for you

Technical specifications

Packaging type: Piece

Product type: PCB connector

Connector type: PCB connector

Features: + sleeve

CS: 3.81 mm

Total number of pins: 12

Content: 1 pc(s)

Stripping length (max.): 7.0 mm

Connection: Print

Case material: PA 6.6

Manufacturer part #: 51550122025D

Factory colour: Green

Contact material: Bronze

Length: 55.32 mm

max. cross section: 1.5 mm²

Min. cross section: 0.14 mm²

RoHS-compliant: Yes

Connector orientation: Parallel (to the PCB)

Max. temperature: 105 °C

Min. temperature: -40 °C

Type: AKZ1550/12F-3.81-GRÜN
