PUSR USR-EG628-GL USR-EG628-GL Expansion 9, 36 V
Part number:
Item no:
Sales and shipping:
Conrad ElectronicTerms & Conditions
Total (€ 355.00 / piece)
€ 355.00
incl. VAT
Only available for business customers
14-day return policy includedHighlights & Details
USR-EG628-GL ;Expandable IoT Controller, CPU ARM 64-bit 2.0 GHz, 4G, WiFi, Ethernet, GNSS, USB, HDMI, RS485, CAN, I/O Expansion
- SIMATIC S7-200 is easy: programming software with Windows user interface
- instructions for quick access to PLC technology
- easy installation onto a top hat profile rail
- SIMATIC S7-200 is compact: e.g. CPU 222: (W x H x D) 90 x 80 x 62 mm
- own S7-200 net with PPI protocol
- freely programmable interface.
Technical specifications
- Concurrent Displays: -
- Other Features: DI x4, DO (Relay, SPDT) x2, AI (0...10V or 4...20mA) x4
- Wireless Communication: Wi-Fi 802.11 b/g/n, 4G (Global), GNSS (GPS, GLONASS, BDS, Galileo, QZNS)
- Microarchitecture: ARM Cortex-A55, 1 TOPS NPU, 3D GPU
- Cores / Threads: 4 x A55 / 4T
- Power Supply: Mating Connector: Cage Clamp
- OS support: Ubuntu 20.04
- Product type
Expansion
- No. of analogue inputs
4
- No. of digital inputs (max.)
4
- No. of relay outputs (max.)
2
- Operating voltage
9
36 V
- Height
93.15 mm
- Length
60.70 mm
- Width
87.50 mm
- Type
USR-EG628-GL
- Manufacturer part #
USR-EG628-GL
- Dim
(L x W x H) 60.70 x 87.50 x 93.15 mm
- Fitting type (details)
DIN rail
- Engineering Series Name
EG628
- Hard drive
32 GB
- Cooling
Passive
- HDD 1 type
eMMC
- CPU
Rockchip RK3568
- CPU speed
2 GHz
- Interfaces
100 Mb x2, USB 3.2 Gen 1x1, USB 3.2 Gen 1x1 OTG, RS-232 x2, RS-485 x2, CAN, Line-out,
4 GB
- RAM type
DDR4 RAM
- Max. temperature
+70 °C
- Min. temperature
-20 °C
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3639344 PUSR USR-EG628-GL USR-EG628-GL Expansion 9, 36 V
Description
The SIMATIC S7-200 family offers a broad spectrum of modules suitable for the most varied applications. The newly available CPU types and expansion modules enable universal automation concepts with 10 to 248 inputs/outputs. The products of the S7-200 family which are optimally matched to each other also make it easy to change and expand the automation solution in the future.
Application areas such as:
small and special machine construction: packaging, strapping and coiling machines · food industry: kneading, cutting machines, mix granulating machines · laboratories: laboratory mixers, heating cabinets, vacuum pumps, suction equipment.
The CPUs are each offered in 5 different variants, with various connection and control voltages. The PPI interface built into all CPUs enables point-to-point connections to PG/PC, SIMATIC OP, expanded SIMATIC S7-200 and user-defined end devices (printer, bar code reader). With PG/PC or OP as master, a maximum of 31 SIMATIC S7-200 devices can be connected together. If additional inputs/outputs are required, a variety of different expansion modules is available. These are simply linked to the CPU by a connector.
Application areas such as:
small and special machine construction: packaging, strapping and coiling machines · food industry: kneading, cutting machines, mix granulating machines · laboratories: laboratory mixers, heating cabinets, vacuum pumps, suction equipment.
The CPUs are each offered in 5 different variants, with various connection and control voltages. The PPI interface built into all CPUs enables point-to-point connections to PG/PC, SIMATIC OP, expanded SIMATIC S7-200 and user-defined end devices (printer, bar code reader). With PG/PC or OP as master, a maximum of 31 SIMATIC S7-200 devices can be connected together. If additional inputs/outputs are required, a variety of different expansion modules is available. These are simply linked to the CPU by a connector.
Hints
*1: In GL version occupied by 4G module
