Rittal SK 3336.470 Water-cooled radiator 400 V 21.2 kW, 16.6 kW (W x H x D) 900 x 1733 x 1800 mm 1 pc(s)
EAN:
Part number:
Item no:
Product type
Water-cooled radiator
Operating voltage
400 V
Power
21.2 kW
16.6 kW
Rotational speed
135 U/min
Noise emission (max.)
78 dBa
Technical specifications
- Net weight: 444 kg
- Gross weight: 544 kg
- Dimensions: Width 900 mm
- Height: 1,733 mm
- Depth: 1,800 mm
- Benefits: Reduction of the amount of refrigerant by Microchannel technology
- Touch-display for simplified user navigation
- Remote monitoring (monitoring) already integrated in the basic device
- Built-in security features
- Pre-configured options
- Colour: Housing: RAL 7035
- RAL 7016 socket
- Design: Robust industry standard
- Potential-free contact for collective fault reporting
- Total cooling power TW10/Tu32: Cooling power TW10 Tu32/50 Hz: 29.7 kW
- Cooling power TW10 Tu32/60 Hz: 35.7 kW
- Total cooling power Tw18 / Tu32: Cooling power Tw18 Tu32/50 Hz: 37.8 kW
- Cooling power TW18 Tu32/60 Hz: 45.1 kW
- Total cooling power according to DIN EN 14511 TW18/Tu35: Cooling power TW18 Tu35/50 Hz: 36.5 kW
- Cooling performance TW18 Tu35/60 Hz: 46.6 kW
- Air flow (free-blowing): At 50 Hz: 12,000 m³/h.
- At 60 Hz: 14,500 m³/h
- Rated operating voltage 400 V, 3~, 50 Hz
- 460 V, 3~, 60 Hz
- Sound pressure level 78 dB(A)
- Operating temperature range -10°C...43°C.
- Operating temperature range for coolant 10°C...25°C.
- Temperature hysteresis ± 2 K
- Refrigerant/coolant: Refrigerant: R410A
- Quantity: 2.9 kg
- Global Warming Potential (GWP): 2,088
- CO2 equivalent (CODOS e): 6.06 t
- Pump pressure 2 bar
- Volume flow (cooling medium): At 50 Hz: 90 l/min.
- At 60 Hz 135 l/min
- Nominal capacity Pel: At 50 Hz: 16.6 kW
- At 60 Hz: 21.2 kW
- Rated current max.: At 50 Hz: 29.7 A
- At 60 Hz 32.7 A
- Water connections R 1½" IG
- Number of cold circuits: 1
- Tank: Material: Stainless steel AISI304 - 1.4301 (V2A)
- Volume: 185 l
- Operating weight 700 kg
- IP rating according to EN 60 529: IP 44 (electrical system)
- Product type
Water-cooled radiator
- Type
SK 3336.470
- Operating voltage
400 V
- Min. operating voltage
400 V
- Max. operating voltage
460 V
- Operating voltage
400 - 460 V
- Max. current consumption
32.7 A
21.2 kW
16.6 kW
- Rotational speed
135 U/min
- Noise emission (max.)
78 dBa
- Air flow rate
14500 m³/h
12000 m³/h
- Compatible with
Rittal
- Factory colour
Grey (RAL 7035)
- Min. temperature
+10 °C
- Max. temperature
+43 °C
IP44
- Width
900 mm
- Height
1733 mm
- Depth
1800 mm
- Dim
(W x H x D) 900 x 1733 x 1800 mm
- Weight
444 kg
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3389223 Rittal SK 3336.470 Water-cooled radiator 400 V 21.2 kW, 16.6 kW (W x H x D) 900 x 1733 x 1800 mm 1 pc(s)
Description
SK Blue e Chiller 36.5/46.6 kW, 400 V, 3~, 50 Hz, 460 V, 3~, 60 Hz, BHT 900 x 1,733 x 1,800 mm
The Blue e Chillers in the stand housing provide a central and economical cooling of the cooling water. A reduction of the refrigerant is achieved through the Microchannel technology. Intuitive operation via touch-display as well as intelligent communication interfaces make the operation and analysis easy. Integrated security features in the standard achieve maximum security. The delivery time is also shortened with predefined option packages.
This text is machine translated.
The Blue e Chillers in the stand housing provide a central and economical cooling of the cooling water. A reduction of the refrigerant is achieved through the Microchannel technology. Intuitive operation via touch-display as well as intelligent communication interfaces make the operation and analysis easy. Integrated security features in the standard achieve maximum security. The delivery time is also shortened with predefined option packages.
This text is machine translated.
