Name: Roline Keystone mount including shielded CAT.6A Keystone, for mounting on DIN rail/top-hat rail... 26.11.0379 Grey 1 pc(
Brand: Roline
SKU: 3799353

Roline Keystone mount including shielded CAT.6A Keystone, for mounting on DIN rail/top-hat rail... 26.11.0379 Grey 1 pc(-0

Roline Keystone mount including shielded CAT.6A Keystone, for mounting on DIN rail/top-hat rail... 26.11.0379 Grey 1 pc(-1

Roline Keystone mount including shielded CAT.6A Keystone, for mounting on DIN rail/top-hat rail... 26.11.0379 Grey 1 pc(-2

Roline Keystone mount including shielded CAT.6A Keystone, for mounting on DIN rail/top-hat rail... 26.11.0379 Grey 1 pc(-3

Roline Keystone mount including shielded CAT.6A Keystone, for mounting on DIN rail/top-hat rail... 26.11.0379 Grey 1 pc(-4

1/5

Product type

RJ45 plug

Type

26.11.0379

Weight

0.05

Factory colour

Grey

Content

1 pc(s)

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Keystone mount including shielded CAT.6A Keystone, for mounting on DIN rail/top-hat rail...

Keystone holder including Keystone
Cable routing can be done 45° from the top or bottom
Holder with integrated dust protection flap
For 26 AWG (0.40 mm) cables – 22 AWG (0.65 mm)
For cables with an external diameter of 5.0 – 8.0 mm

Technical specifications

Product group: Connection technology TP
Product type: Rail mount adapter
Colour: grey
Shielding type: Shielded
Transmission quality Cat6A/Class EA
Number of ports: 1
ASSIGNMENT EIA/TIA 568A & 568B
Material (casing): ABS + Zinc alloy
Mating direction 45° inclination
Dimensions (HxWxD): Keystone-holder 78.25 x 17.7 x 63.9 mm, Keystone 21.5 x 14.7 x 34.5 mm
Min. Operating temperature -10 °C
Max. operating temperature: 60 °C
Min. Storage temperature: -40 °C
Storage temperature max. 70 °C.
Height: 78.25 mm
Width 17.7 mm
Depth: 63.9 mm
Weight 36.5 g
Packaging height 10 mm
Package width 60 mm
Packaging depth 60 mm
Package weight: 0.05 kg
Gross weight: 0.05

Type: 26.11.0379

Product type: RJ45 plug

Weight: 0.05

Factory colour: Grey

Content: 1 pc(s)

Width: 17.7 mm

Height: 78.25 mm

Cable design: Round

Version: Cable

Depth: 63.9 mm

Cable use: C13/C14 appliances

Mounting type: DIN rail

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 3799353 Roline Keystone mount including shielded CAT.6A Keystone, for mounting on DIN rail/top-hat rail... 26.11.0379 Grey 1 pc(

User & Safety Instructions

User & Safety Instructions 3799353 Roline Keystone mount including shielded CAT.6A Keystone, for mounting on DIN rail/top-hat rail... 26.11.0379 Grey 1 pc(

Description

Keystone mount including shielded CAT.6A Keystone, for mounting on a mounting rail / DIN rail cable entry 45° from above or below, connection direction 45° downwards. Holder with integrated dust protection cap. With shield plate (earthing). Keystones with printed color coding according to EIA / TIA 568. Connection of the cable to the Keystones is done without any tools - the cable wires are simply inserted in the guides; the module is closed and compressed - and you are done the connection. For cables with an external diameter of 5.0 – 8.0 mm. Suitable for cables with 26 AWG (0.40 mm) – 22 AWG (0.65 mm). Keystone mount dimensions 78.25 x 17.7 x 63.9 mm Keystone dimensions 21.5 x 14.7 x 34.5 mm

This text is machine translated.
