Rutenbeck 12 x LC-D OS2 blau FO splice box 12 ports LC Equipped 1 U
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Product type
FO splice box
LC
- Patch panel design
Equipped
Pigtail
- Port
12 ports
Singlemode OS2
- Fibre type
9/125 µ
- Cable feed
reverse
- Rack unit
1 U
- Factory colour
Black
- Length
245 mm
- Width
482 mm
- Height
44 mm
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2744280 Rutenbeck 12 x LC-D OS2 blau FO splice box 12 ports LC Equipped 1 U
User & Safety Instructions
User & Safety Instructions 2744280 Rutenbeck 12 x LC-D OS2 blau FO splice box 12 ports LC Equipped 1 U
Description
Basic-Line splicebox, extendable, 19"smaller than br/greater than/1HE, 12xLC-D, OS2, Blue powder coated steel casing Factory port marking Removable drawer solution in the open condition inclined downward with snap closure on front side (push-pull) with 2 splice cartridges for the acceptance of 12 or 24 pigtails inserted crimp splice holder prepared with 12 pc set of pigtails including 12 x LC-D ceramic couplings 24 LC fiber pigments E9/125 µm, 2 m, SM PC, Grade C with measuring protocol for all fibers incl. Serial number 2 x PG13,5/M20-screw joints (each 2 x right/left) 1 x PG13.5/M20-screw connection included in delivery black (similar to RAL 9005)
