Rutenbeck 2280302120 FO splice box Optical fiber Equipped 1 U
EAN:
Part number:
Item no:
Technical specifications
- Suitable for number of couplings/adapters: 24
- With number of couplings/adapters 12
- With front panel: Yes
- With housing: Yes
- With pigtails: Yes
- Fibre type: Multimode 50/125
- Fibre class OM5
- External plug connector: LC duplex
- Inner connector type: LC-Duplex
- Colour, black
- RAL number: 9005
- Mounting type 482.6 mm (19 inch) mounting
- Number of height units (RUs): 1
- Height: 44 mm
- Width 482 mm
- Depth: 245 mm
- Product type
FO splice box
Optical fiber
- Patch panel design
Equipped
Pigtail
Multimode OM5
- Fibre type
50/125 µ
- Rack unit
1 U
- Factory colour
Black
- Width
482.00 mm
- Height
44.00 mm
- Depth
245.00 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 3134016 Rutenbeck 2280302120 FO splice box Optical fiber Equipped 1 U
Description
BasicLine splice box, extendable, 19"
/1HE, 12xLC-D, OS2, blue, powder-coated steel casing, Factory port marking, extendable drawer solution, inclined downward in open condition, with snap closure on front side (push-pull), with splice box to accommodate 12 or 24 pigtails, inserted crimp splice holder, prepared with 12-pack of inserted pigtails including 12 x LC-D ceramic couplings, 24 LC fiber pigments E9/125 µm, 2 m, SM PC, Grade B- with measuring protocol for all fibers including serial number, mounted blanking plugs for less than 12 ports, 2 x back-sided PG13.5/M20 fittings (2 x right/left each), 1 x PG13.5/M20 screw fitting included, black (similar to RAL 9005)
This text is machine translated.
/1HE, 12xLC-D, OS2, blue, powder-coated steel casing, Factory port marking, extendable drawer solution, inclined downward in open condition, with snap closure on front side (push-pull), with splice box to accommodate 12 or 24 pigtails, inserted crimp splice holder, prepared with 12-pack of inserted pigtails including 12 x LC-D ceramic couplings, 24 LC fiber pigments E9/125 µm, 2 m, SM PC, Grade B- with measuring protocol for all fibers including serial number, mounted blanking plugs for less than 12 ports, 2 x back-sided PG13.5/M20 fittings (2 x right/left each), 1 x PG13.5/M20 screw fitting included, black (similar to RAL 9005)
This text is machine translated.
