Safety relay PNOZ X3.10P C 24VACDC 3n/o 1n/c 1so PILZ Operating voltage: 24 V DC/AC 3 makers, 1 breaker (W x H x D) 45 x
Packaging type
Single
Product type
Safety relay
Connector
Spring force connector
Operating voltage
24 V DC/AC
Type
PNOZ X3.10P C 24VACDC 3n/o 1n/c 1so
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Applications: Emergency stop monitoring without delay, limit switches, light barrier monitoring Typ.2 m T, light barrier overw. Typ.2 o T, light barrier overw. Type.4, safety door monitor
- Terminal type: Pluggable
- Number of auxiliary contacts: 1
- Operating modes: Single channel, automatic start, double channel, manual start, cross-circuit detection, manual start with overw, without cross-circuit detection
- Standards: EN 60204-1, EN 62061, EN ISO 13849-1, VDE 0113-1
- Number of safety contacts without delay: 3
- Number of safety contacts delayed: 0
- Product standard: EN 60947-5-1
- Number of semiconductor outputs
- :
- Max 0. Current at AC15: 5.0 A.
- Packaging type
Single
- Product type
Safety relay
- Type
PNOZ X3.10P C 24VACDC 3n/o 1n/c 1so
- Connector
Spring force connector
- Operating voltage
24 V DC/AC
- Min. operating voltage
24 V DC/AC
- Max. operating voltage
240 V DC/AC
- Operating voltage
24 - 240 V DC/AC
- Contact type
3 makers
1 breaker
- Switching voltage (max.)
240 V AC
- Switching current (max.)
6.0 A
- Features
Manual/auto reset
- Operating temperature (min.)
-20 °C
- Operating temperature (max.)
+55 °C
- Depth
121 mm
- Width
45 mm
- Height
101 mm
- Dim
(W x H x D) 45 x 101 x 121 mm
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2182939 Safety relay PNOZ X3.10P C 24VACDC 3n/o 1n/c 1so PILZ Operating voltage: 24 V DC/AC 3 makers, 1 breaker (W x H x D) 45 x
User & Safety Instructions
User & Safety Instructions 2182939 Safety relay PNOZ X3.10P C 24VACDC 3n/o 1n/c 1so PILZ Operating voltage: 24 V DC/AC 3 makers, 1 breaker (W x H x D) 45 x
Description
Our safety switching devices PNOZ X have proven their reliability and robustness. They are used in a wide range of applications and in a wide variety of safety applications. You use a PNOZ X for each safety function. The technical basis here are potential-free, electromechanical contacts in the 2-relay technology. The sizes vary from 22.5 to 90 mm, the number of contacts from two to eight. Whatever your security requirements, PNOZ X has already proven itself millions of times in the tough industrial environment.
