Sauter TVO 500N500S-LD Test stand set 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
Test stand set incl. length meter Sauter TVO 500N500S-LD
- Practical set for power-way measurements in the laboratory and industry
- This text is machine translated.
Technical specifications
- Product type
Test stand set
- Compatible with
Sauter
- Width
570 mm
- Height
236 mm
- Length
300 mm
- Depth
428 mm
- Type
TVO 500N500S-LD
- Series
TVO-LD
- Max. ambient temperature
40 °C
- Min. ambient temperature
10 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 3702099 Sauter TVO 500N500S-LD Test stand set 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3702099 Sauter TVO 500N500S-LD Test stand set 1 pc(s)
Information
Information 3702099 Sauter TVO 500N500S-LD Test stand set 1 pc(s)
Description
Features
- Five in one – motorized test bench, length measuring system LD, interface cable, data transfer software AFH LD, interface converter AFH 12 and mounting
- With linear potentiometer for length measurement to create force-path diagrams on the PC, maximum measurement range 300 mm, 0.01 mm readability, 0.5% measurement accuracy of [Max], 1.5 m USB-A cable, high data acquisition speed
- Motorized test stand for track and compression force measurements
- Stepper motor for optimum operation:- for constant speed from minimum to maximum load- enables testing at minimum speed and full load- for higher positioning accuracy. Precise starting and stopping, without lagging, even at high speeds- most accurate setting of traverse speed with display in the display
- Automatic or manual traversing mode
- Premium control panel:- Digital speed display- Digital repeat function- Control of the test stand using PC software Sauter AFH
- Table design for easy operation
- Robust construction
- Mounting options for Sauter force meters up to 500 N, only in conjunction with TVO-A01 (see accessories);
