Schabus 300749 SHT 5002 Water leak detector Filling, Draining

The water detector SHT 5002 is a device for level control (2-point control). Over two water sensors or floating switches, an upper and a lower level and can be used for automatic filling or draining of a container. A potential-free relay contact is used to control the pump (Relay K1 Level: max. 5 A/230 V, relay K2 Overflow: max. 5 A/230 V).
Overflow message: In addition, the water detector SHT 5002 another sensor input for an overflow message (e.g. in the event of a failure of the pump) with potential-free relay contact. For example, a signalling device, solenoid-valve, a telephone dialling device or a bus system can be controlled.
Memory function overflow message: via wire-bridges, there is the possibility to save the overflow message and acknowledge by pressing the button. The default setting is after falling below the water level the overflow message is automatically deleted. Application areas: Level Control cistern or for pump control (vessel empty or filling).

This text is machine translated.
