Schlegel YMTLY YMTLY Pushbutton illuminable manually, 1-button 5 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Highlights & Details
"Schlegel pushbutton YMRLY 5 pcs."
Our service for you
Technical specifications
- Protection class II (protective insulation)
- Lighting: Yes
- Writable: no.
- Front frame: Silver-colored
- Shape: Round
- Product type
Pushbutton
- Switch/button features
illuminable
- Lighting type
LED
- Bulb type
LED (monochrome)
- Operation type
manually
1-button
- Colour
Yellow
- Connection
CEE 7/16 CEE plug
- Functions
momentary
- Contact type
1 maker
- Durability
500000
- Electrical lifespan
500000
- Recess diameter
16.2 mm
IP65
IP67
- Min. temperature
-25 °C
- Max. temperature
+70 °C
- Switching voltage
30 V AC
42.4 V
- Switching current (max.)
100 mA
- Switch position
1 x Off/(On)
- Length
22 mm
- Width
24 mm
- Height
24 mm
- Compatible with (details)
Series: MYnitron®
- Content
5 pc(s)
- Dim
(L x W x H) 22 x 24 x 24 mm
- RoHS-compliant
Yes
- Type
YMTLY
