Name: Schlegel YMTW_0001 YMTW_0001 Pushbutton writable manually, 1-button 5 pc(s)
Brand: Schlegel
SKU: 2238418

A round, silver vote button with a black arrow symbol, pointing upwards.

A black arrow points upwards in a white circle. This typically symbolises direction or upward movement.

Schematic representation of a circular electronic component with dimensions: diameter 23.5 mm, height 4 mm and 18 mm.

Diagram shows a switch with four terminals: 'E', '3', '+', '-', '4'. Lines connect terminals, symbolising a circuit.

1/4

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

"Schlegel pushbutton YMTW_0001 5 pcs."

Our service for you

Technical specifications

Protection class II (protective insulation)
Lighting: no.
Inscribable: Yes
Front frame: Silver-colored
Shape: Round

Product type: Pushbutton

Switch/button features: writable

Lighting type: None

Operation type: manually
1-button

Print motif: ↑

Connection: CEE 7/16 CEE plug

Functions: momentary

Contact type: 1 maker

Durability: 500000

Electrical lifespan: 500000

Recess diameter: 16.2 mm

: IP65
IP67

Min. temperature: -25 °C

Max. temperature: +70 °C

Switching voltage: 30 V AC
42.4 V

Switching current (max.): 100 mA

Switch position: 1 x Off/(On)

Length: 22 mm

Width: 24 mm

Height: 24 mm

Compatible with (details): Series: MYnitron®

Content: 5 pc(s)

Dim: (L x W x H) 22 x 24 x 24 mm

RoHS-compliant: Yes

Type: YMTW_0001
