Schneider Electric 18766 18766 Circuit breaker
Product type
Circuit breaker
Release characteristics
B
Dim
(L x W x H) 81 x 81 x 103 mm
Content
1 pc(s)
Switch-off capacity
100000 A
EAN:
Part number:
Item no:
Technical specifications
- Product type
Circuit breaker
- Release characteristics
B
- Dim
(L x W x H) 81 x 81 x 103 mm
- Content
1 pc(s)
- Switch-off capacity
100000 A
- Width
81 mm
- Height
103 mm
- Length
81 mm
- Depth
81 mm
IP20
- Connection
Clamp
- Switching current (max.)
63 A
- Switching voltage
375 V DC
240 V AC
415 V AC
440 V AC
500 V AC
- Durability
20000 cycles
- Max. temperature
+70 °C
- Min. temperature
-30 °C
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1859549 Schneider Electric 18766 18766 Circuit breaker
Description
Schneider Electric 18766. Nominal current 63 A, rated voltage 500 V, AC input frequency: 50 - 60. Type: B-type, Switching power: 100000 A, degree of protection (IP Code): IP20. Width: 81 mm, Depth: 81 mm, Height 103 mm
