Schneider Electric NSYCVF165M230PF Fan unit 230 V (W x H x D) 248 x 268 x 104 mm Piece 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Fan unit
Operating voltage
230 V
Noise emission (max.)
51 dB
Width
248 mm
Technical specifications
- Packaging type
Piece
- Product type
Fan unit
- Type
NSYCVF165M230PF
- Features
incl. filter
- Operating voltage
230 V
- Noise emission (max.)
51 dB
- Air flow rate
193 m³/h
- Factory colour
Grey
- Min. temperature
-20 °C
- Max. temperature
60 °C
IP54
- Width
248 mm
- Height
268 mm
- Depth
104 mm
- Dim
(W x H x D) 248 x 268 x 104 mm
- Weight
1.5818 kg
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1866134 Schneider Electric NSYCVF165M230PF Fan unit 230 V (W x H x D) 248 x 268 x 104 mm Piece 1 pc(s)
Description
Clima Sys-Lufter IP54, 165 m³/h, 230 V, with output mesh grill and filter G2. Product Series: ClimaSys CV-Series: ClimaSys-Product Name: CV-product or component type: air ventilation filter type: Standard air current: free-flow rate with standard filter: 165 m3/h at 50 Hz, free-flow rate with standard filter: 193 m3/h at 60 Hz.
