Schneider Electric NSYCVF550M24FB Fan unit 24 V (W x D) 223 mm x 90 mm Piece 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Fan unit
Operating voltage
24 V
Noise emission (max.)
60 dB
Width
223 mm
Technical specifications
- Packaging type
Piece
- Product type
Fan unit
- Type
NSYCVF550M24FB
- Operating voltage
24 V
- Noise emission (max.)
60 dB
- Air flow rate
550 m³/h
- Factory colour
Dark grey
- Min. temperature
-20 °C
- Max. temperature
50 °C
IP55
- Width
223 mm
- Depth
90 mm
- Dim
(W x D) 223 mm x 90 mm
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1863943 Schneider Electric NSYCVF550M24FB Fan unit 24 V (W x D) 223 mm x 90 mm Piece 1 pc(s)
Description
ClimaSys CVHD HD Ventilatorbox for au? en without grille and filter 550 m3/h 24 VDC. Series: ClimaSys-Product Name: CV-product or component type: Fan without grille and filter-product-specific application: Au? eneinsatz heavy load-compatible product family: Thalassa - PHD, spacial SFHD, spacial S3 HD-air current: Flow rate: 550 m3/h at 50 Hz, 550 m3/h at 60 Hz - product eco-design directive 2009/125/EC, UL certifications: gema? UL 508A, CSA gema? CSA C22.2, CE.
