Schneider Electric NSYCVF575M230MF Fan unit 230 V (W x H x D) 340 x 96 x 340 mm Piece 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Fan unit
Operating voltage
230 V
Noise emission (max.)
64 dB
Width
340 mm
Technical specifications
- Packaging type
Piece
- Product type
Fan unit
- Type
NSYCVF575M230MF
- Features
incl. filter
- Operating voltage
230 V
- Noise emission (max.)
64 dB
- Air flow rate
575 m³/h
- Factory colour
Grey
IP54
- Width
340 mm
- Height
96 mm
- Depth
340 mm
- Dim
(W x H x D) 340 x 96 x 340 mm
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1866161 Schneider Electric NSYCVF575M230MF Fan unit 230 V (W x H x D) 340 x 96 x 340 mm Piece 1 pc(s)
Description
Climasys-Lufter, 575 m³/h, 230 V, with roof mesh grill and filter G2. Product Series: ClimaSys CV-Series: ClimaSys-Product Name: CV-product or component type: upper hood with fan-compatible product family: Prism Prism PH, Prism Prism P, Prism prism iPM M, Activsense 9 cabinet ventilation filter type: G2-air current: Flow rate: 575 m3/h at 50 Hz, 291 x 291 mm mit outlet cricket cut-out: 350 m3/h.
