Schneider Electric NSYTBP24198 PC casing 175 x 241 x 87 Polycarbonate (PC) Grey-white (RAL 7035) 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
PC casing
Material
Polycarbonate (PC)
IP rating
IP66
Width
175 mm
Technical specifications
- Packaging type
Piece
- Product type
PC casing
- Features
wallmount option
- Material
Polycarbonate (PC)
IP66
- Factory colour
Grey-white (RAL 7035)
- Width
175 mm
- Height
241 mm
- Dimensions
194 x 241 x 87 mm
- Weight
0.64 kg
- Content
1 pc(s)
- Type
NSYTBP24198
- Dim
(W x H x D) 175 x 241 x 87 mm
- Manufacturer part #
NSYTBP24198
- Depth
87 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1866420 Schneider Electric NSYTBP24198 PC casing 175 x 241 x 87 Polycarbonate (PC) Grey-white (RAL 7035) 1 pc(s) Piece
Description
PC-CAS. IP66 IK08 RAL 7035 In. H 225 B 175 D80 Au?. H241B 194 D 194 undur. PC-cover. H20. Product Series: TeSys GF-Device Application: Multi-purpose-Height: 241 mm width: 194 mm depth: 87 mm inner height: 225mm Internal width: 175 mm internal depth: 80mm cabinet installation: wall mounting device structure: 1 x cover, 4 x cover screw, 1x housing - Housing Type: One-piece molded shape-mounting the cover: plastic screws.
This text is machine translated.
This text is machine translated.
