Schneider Electric NSYTBP292416H PC casing 168 x 225 x 291 x 168 Polycarbonate (PC) Grey-white (RAL 7035) 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
PC casing
Material
Polycarbonate (PC)
IP rating
IP66
Width
225 mm
Technical specifications
- Packaging type
Piece
- Product type
PC casing
- Features
wallmount option
- Material
Polycarbonate (PC)
IP66
- Factory colour
Grey-white (RAL 7035)
- Length
168 mm
- Width
225 mm
- Height
291 mm
- Dimensions
291 x 241 x 168 mm
- Weight
1.24 kg
- Content
1 pc(s)
- Type
NSYTBP292416H
- Dim
(L x W x H) 168 x 225 x 291 mm
- Manufacturer part #
NSYTBP292416H
- Depth
168 mm
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1866426 Schneider Electric NSYTBP292416H PC casing 168 x 225 x 291 x 168 Polycarbonate (PC) Grey-white (RAL 7035) 1 pc(s) Piece
Description
PC-CAS. IP66 IK08 RAL 7035 In. H275B225D160 Au?. H291 B241D 168 undur. PC-cover. H 60. Product Series: TeSys GF-Device Application: Multi-purpose-Height: 291 mm width: 241 mm depth: 168 mm - Inner height: 275mm Internal width: 225 mm internal depth: 160 mm cabinet installation: wall mounting device structure: 1 x housing, 1 x cover, 4 x cover screw-type: One-piece molded shape-mounting the cover: plastic screws.
This text is machine translated.
This text is machine translated.
