Schneider Electric NSYTBP29248 PC casing 225 x 291 x 88 Polycarbonate (PC) Grey-white (RAL 7035) 1 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
PC casing
Material
Polycarbonate (PC)
IP rating
IP66
Width
225 mm
Technical specifications
- Packaging type
Piece
- Product type
PC casing
- Features
waterproof
- Material
Polycarbonate (PC)
IP66
- Factory colour
Grey-white (RAL 7035)
- Width
225 mm
- Height
291 mm
- Dimensions
291 x 241 x 88 mm
- Weight
0.86 kg
- Content
1 pc(s)
- Type
NSYTBP29248
- Dim
(W x H x D) 225 x 291 x 88 mm
- Manufacturer part #
NSYTBP29248
- Depth
88 mm
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1866428 Schneider Electric NSYTBP29248 PC casing 225 x 291 x 88 Polycarbonate (PC) Grey-white (RAL 7035) 1 pc(s) Piece
Description
PC-CAS. IP66 IK08 RAL 7035 In. H275B225D80 Au?. H291 B241D88 undur. PC-cover. H20. Product Series: TeSys GF-Device Application: Multi-purpose-Height: 291 mm width: 241 mm depth: 88 mm inner height: 275mm Internal width: 225 mm internal depth: 80mm cabinet installation: wall mounting device structure: 1 x housing, 1 x cover, 4 x cover screw-type: One-piece molded shape-mounting the cover: plastic screws.
This text is machine translated.
This text is machine translated.
