Name: Schneider Electric VBDN20 Circuit breaker 1 pc(s) Switching voltage (max.): 690 V AC (W x H x D) 60 x 60 x 123.5 mm
Brand: Schneider Electric
SKU: 2375006

A black rotary switch from Schneider Electric. The 'Off' and 'On' positions are indicated, with the lever set to 'Off'.

Image similar

Product type

Circuit breaker

Connection

Screw terminal

Type

VBDN20

Current load

11 A

No. of pins

3-pin

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Design: Lockable
Operating type: Rotary drive
Locking with turning handle: 1 to 3 padlocks 4…8 mm
Conventional thermal current 20 A.
Mechanical life: 50000 cycles
Dimensions of handle front panel: 60 x 60 mm
PVC-free: Yes

Product type: Circuit breaker

Type: VBDN20

Current load: 11 A

No. of pins: 3-pin

Switching voltage (max.): 690 V AC

Mounting type: Fixed

Min. temperature: -20 °C

Max. temperature: +50 °C

Connection: Screw terminal

: IP65

Depth: 123.5 mm

Width: 60 mm

Height: 60 mm

Dim: (W x H x D) 60 x 60 x 123.5 mm

Content: 1 pc(s)

UKCA: yes
