Schurter 3-153-714 IEC connector Total number of pins: 3 + PE 10 A White 1 pc(s) Piece
Part number:
Item no:
Packaging type
Piece
Product type
IEC connector
Plug standard (IEC 60320)
C14
Total no. of pins
3 + PE
Connection
Type C CEE 7/16 plug 6.3 mm
Datasheet (PDF)
Highlights & Details
DG11 IEC-C14 Combi Mag. W 10A 2F IP67
- IEC device plug C14 with rocker switch
- Power switch not illuminated
- 2 Functions: Device plug protection class I, device protection switch type TA35, mains switch 2-pin, with magnet module: Flink
Technical specifications
- Series DG11
- Connection: Spade connector 6.3x0.8 mm
- Design: Rectangular
- Housing: Plastic
- Design: Board
- Mounting type: Front side
- Locking: Yes
- Mounting: Screw fixing
- Board thickness, max. 8 mm
- Alternative part number: DG11-CBDWM100F2-000-C6135-331-881-00
- Contact type: Plug
- Wippe color: White
- Contact: Plug
- Contact type C14
- Application: Suitable for use in devices according to IEC/UL 62368-1, suitable for devices of protection class I according to IEC 61140
- Alignment: Straight
- Protective conductor: 1
- Locking type: Latch
- Pen temperature 70 °C
- NOMINAL VOLTAGE AC 250 V AC
- Connection for 6.3 mm spade connector
- Starting torque 0.25 Nm
- Plug-in force per contact, min. 60 N
- Flange-hole spacing 38 mm
- Approvals: ENEC 10|cURus|CCC|CE|UKCA
- IP protection class front side IP67
- Packaging type
Piece
- Product type
IEC connector
- Plug standard (IEC 60320)
C14
- Total no. of pins
3 + PE
- Connection
Type C CEE 7/16 plug 6.3 mm
- Factory colour
White
- Content
1 pc(s)
- Nominal current
10 A
- Nominal current - rounded value
10 A
- Case material
Plastic
- Manufacturer part #
3-153-714
- Fitting type (details)
Installation
- Certification marks
IEC 60320-1|UL 60320-1|CSA C22.2 NO. 60320-1
- Number of pins
3
- Width
51 mm
- Height
68 mm
- Length
38 mm
- RoHS-compliant
Yes
- Type
3-153-714
- Leading contact (PE)
Yes
- Depth
75.4 mm
- Enclosure material
Thermoplastic
- Operating temperature (max.)
60 °C
- Operating temperature (min.)
-25 °C
- Flammability rating
UL 94 V0
- Protection class
I
Documents & Downloads
Datasheet
Datasheet 3738312 Schurter 3-153-714 IEC connector Total number of pins: 3 + PE 10 A White 1 pc(s) Piece
User & Safety Instructions
User & Safety Instructions 3738312 Schurter 3-153-714 IEC connector Total number of pins: 3 + PE 10 A White 1 pc(s) Piece
Description
Schurter built-in cold equipment connector DG11 panel C14 3 pin(s) IP67 plug thermoplastic (TP) 10A 250Vac 70°C 38mm I
