Image similar
Schurter 3403.0155.11 3403.0155.11 SMD fuse 0.08 A 250 V DC Time delay -T- Content 1 pc(s) Bulk
Packaging type
Bulk
Product type
SMD fuse
Nominal voltage
250 V DC
Nominal current - rounded value
80 mA
Release characteristics
Time delay -T-
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Series UMT250
- Dimensions: Length 10.1 mm
- Dimensions: Width 3 mm
- Dimensions: Height 3 mm
- Nominal voltage at 50/60Hz 250 V DC
- Nominal current: 0.08 A
- Approvals CE, VDE, cULus, KTL, CQC
- Trigger time: Slow-blow
- Contact material: Tin-plated copper alloy
- Applications: As primary protection on SMD circuit boards|suitable for pulsed continuous currents
- Casing material: Ceramic
- SMD connection type
- Material: Copper alloy, tin plated
- Weight: 0.23 g
- Min. Operating temperature range -55 °C.
- Operating temperature range, max. 125 °C.
- Climate category IEC 55/125/21
- Melting Integral: 0.022 A²/s.
- Rated breaking capacity 200 A.
- NOMINAL VOLTAGE V AC 250 V AC
- Voltage drop 1,300 mV
- Loss rating, max. 200 mW
- Soldibility 245 °C / 30 s
- IEC 60127-4 standard
- Packaging type
Bulk
- Product type
SMD fuse
- Nominal voltage
250 V DC
- Nominal current
0.08 A
- Nominal current - rounded value
80 mA
- Switch-off capacity
200 A
- Release characteristics
Time delay -T-
- Fuse layout
Ceramic tube
- Length
10.10 mm
- Certification marks
IEC 60127-4
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
3403.0155.11
Documents & Downloads
Datasheet
Datasheet 3306260 Schurter 3403.0155.11 3403.0155.11 SMD fuse 0.08 A 250 V DC Time delay -T- Content 1 pc(s) Bulk
User & Safety Instructions
User & Safety Instructions 3306260 Schurter 3403.0155.11 3403.0155.11 SMD fuse 0.08 A 250 V DC Time delay -T- Content 1 pc(s) Bulk
Description
SMD fuse
slow-blow
High breaking capacity of 200 A @ 250 V AC (IEC)
UL approval for 277V AC and 250V DC
Loose goods
This text is machine translated.
slow-blow
High breaking capacity of 200 A @ 250 V AC (IEC)
UL approval for 277V AC and 250V DC
Loose goods
This text is machine translated.
