Image similar
Schurter 8020.5011 8020.5011 Micro fuse (Ø x L) 6.3 mm x 32 mm 1.00 A 400 V DC Time delay -T- Content 1 pc(s)
Product type
Micro fuse
Nominal voltage
400 V DC
Nominal current - rounded value
1 A
Release characteristics
Time delay -T-
Length
32 mm
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Series: SHT
- Nominal voltage at 50/60Hz 400 V DC
- Nominal current 1 A
- Approvals: CULus
- Trigger time: Slow-blow
- Contact material: Nickel-plated copper alloy
- 6.3 x 32 mm case
- Applications: Suitable for: 3-phase applications, DC-applications, photovoltaics, frequency converters, power electronics and commercial cooking devices
- Casing material: Ceramic
- Weighs 2.84 g.
- Min. Operating temperature range -40 °C.
- Operating temperature range, max. 85 °C.
- Climate category IEC 40/85/21
- Melting Integral: 1.55 A²/s.
- NOMINAL VOLTAGE V AC 500 V AC
- Voltage drop 350 mV
- Loss rating, max. 900 mW
- UL 248-14 standards
- Product type
Micro fuse
- Nominal voltage
400 V DC
- Dim
(Ø x L) 6.3 mm x 32 mm
- Nominal current
1.00 A
- Nominal current - rounded value
1 A
- Switch-off capacity
3500 A
- Release characteristics
Time delay -T-
- Fuse layout
Ceramic tube
- Length
32 mm
- (Ø)
6.3 mm
- Certification marks
UL 248-14
- Content
1 pc(s)
- RoHS-compliant
Yes
- Type
8020.5011
Documents & Downloads
Datasheet
Datasheet 3306210 Schurter 8020.5011 8020.5011 Micro fuse (Ø x L) 6.3 mm x 32 mm 1.00 A 400 V DC Time delay -T- Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3306210 Schurter 8020.5011 8020.5011 Micro fuse (Ø x L) 6.3 mm x 32 mm 1.00 A 400 V DC Time delay -T- Content 1 pc(s)
Description
G fuse
High rated voltages of up to 500V AC and 400V DC
High breaking capacity of up to 3500A
Suitable for continuous pulse-shaped currents
Used for commercial cooking appliances according to UL 197
This text is machine translated.
High rated voltages of up to 500V AC and 400V DC
High breaking capacity of up to 3500A
Suitable for continuous pulse-shaped currents
Used for commercial cooking appliances according to UL 197
