Highlights & Details

Switchable IP socket with which a grounding socket is switched and monitored and the current power consumption can be measured.

1x ground contact socket<>br breaking capacity 10A with 2300Watt<>
temperature range -40°C. + 70°C
Housing: Shock-proof ABS plastic

Technical specifications

Product group: Power strips
Product type<>: IP Power switch br Function: Remote switching via IP
Design: Socket adapter
Max. Load capacity: 2300 W<>max. Voltage: 230V
On/off switch: Yes
Switch type: IP
Number of socket pots: 1
Number of outputs/angle: 1
Layout Outputs: straight
Dimensions (HxWxD)<><>: 135 x 55 x 40 mm135 x 55 x 40 mm (LxWxH) 40x55x135 br Material (casing): plastic br Colour (casing): gray br<>Connection plug: Protection contact
Technical characteristics: current consumption measurement
Height<><><>: 135 mm br Width: 55 mm br Depth: 40 mm br Weight: 0.2 kg
Gross weight: 0.282
Current catalog issue: 22.1
Current catalog page: 0

Product type: Socket

Content: 1 pc(s)

Cable length: 0 cm

Keyboard layout: German, QWERTZ

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 3797275 Secomp 19.07.1499 Socket

User & Safety Instructions

User & Safety Instructions 3797275 Secomp 19.07.1499 Socket

Description

Switchable IP - socket with which a safety socket is switched, monitored and the current power consumption can be measured. With the integrated micro-switch you do not need an additional network cable, since the SecureSocketSwitch has two integrated network connections. The high-performance and safety relay with silver-zinc oxide contacts (AgSnO2) offers a high switching power, a long service life and reliable and interference-free operation. The network connection is provided by default by means of a 1024-bit SSL encryption and can be additionally secured or extended by server and client certificates. The consumption data is recorded for up to 30 days and can be displayed on the WEB monitor. Many additional programmable software functions enable a targeted and efficient control, reduction or optimization of the power consumption. The SecureSocketSwitch is light, simple and always accessible via the Internet. Without Apps and without Tools.

This text is machine translated.
