Senseca ECO 210-3-UT Pressure gauge Calibrated to (ISO standards) Pressure 2000 hPa (max)
Datasheet (PDF)
EAN:
Part number:
Item no:
Technical specifications
- Display units Pa, hPa, mbar, PSI, mmHg
- Measuring frequency: Slow 2.5 measurements/s; fast 25 measurements/s.
- Overload max.: +/- 1700 hPa
- Working temperature: -20°C to +50 °C
- Power supply (details)
2 x AA battery
- Product type
Pressure gauge
- Reading range
2000 hPa (max)
- Power consumption
1 mA
- Unit of measurement
Pressure
- Pneumatic connection
2 hose connections, changeable through G1/8 universal ports
- Reading range
Selectable from -2000..+2000 Pa to -200.0..+200.0 hPa (FINE: -200.0..+200.0 Pa)
ISO standards
- Display range
Pa, hPa, mbar, PSI, mmHg (Torr)
- Print resolution
0.1 Pa
IP67
- Dim
(L x W x H) 54 x 28 x 108 mm
- Weight
150 g
- Accuracy
0.1 %
- Reading range (max.)
2000 hPa
- Width
28 mm
- Height
108 mm
- Length
54 mm
Documents & Downloads
Datasheet
Datasheet 3220315 Senseca ECO 210-3-UT Pressure gauge Calibrated to (ISO standards) Pressure 2000 hPa (max)
User & Safety Instructions
User & Safety Instructions 3220315 Senseca ECO 210-3-UT Pressure gauge Calibrated to (ISO standards) Pressure 2000 hPa (max)
Description
While developing the new ECO-line the main focus was placed on the essential functions of the measurement technology. The heart of the device - the sensor - is a high-quality component - which is characterized in this device class. The high reliability, speed and precision of the ECO-line versions, packed in a compact and water-protected casing makes the devices an ideal partner for industry and trade, Made in Germany. ECO 210-3 Fine pressure manometer for use in heating, ventilation and air conditioning systems (HVAC). The measurement range up to 200 hPa (mbar) / 20 kPa and the high resolution up to 0.1 Pascal in optimized fine pressure mode cover the main applications for gas pressure 150 hPa (mbar) and burner setting with a single device. The high precision makes it easier, for example, to set compressed air or draft air measurements. The measurement is independent of the orientation of the device - better than with many, also far more expensive, competitors.
Display
3-line segment LCD
Additional symbols
Illuminated (white, light-on time adjustable)
Overhead display at the touch of a button
Standard functions
Min/Max/Hold
Auto power-off function / If activated, the product switches off automatically
Reconciliation
Zero point and slope setting
Housings
Unbreakable ABS casing
Protection type IP67 (pressure connections must be protected against contamination and moisture)
This text is machine translated.
Display
3-line segment LCD
Additional symbols
Illuminated (white, light-on time adjustable)
Overhead display at the touch of a button
Standard functions
Min/Max/Hold
Auto power-off function / If activated, the product switches off automatically
Reconciliation
Zero point and slope setting
Housings
Unbreakable ABS casing
Protection type IP67 (pressure connections must be protected against contamination and moisture)
This text is machine translated.
Features
- Modern and functional casing in pocket-size
- Excellent value for money
- Backlight
- Robust, long battery life
- Simple universal pressure connection with interchangeable connections
- High resolution and accuracy
- Very fast!
- Made in Germany
