SIBA 160500.4GT Micro fuse SMD 4.00 A 250 V AC Time delay -T- 1 pc(s)
Product type
Micro fuse
Nominal voltage
250 V AC
Nominal current - rounded value
4 A
Release characteristics
Time delay -T-
Type
SMD
Datasheet (PDF)
Part number:
Item no:
Highlights & Details
SIBA SMD-fuse 160500 slow-blow 100A 250Vac 4A 9,5X7,4mm with clip holder
- SMD fuse with clip
- slow-blow
- Very compact design: With clip 7.4x17.5mm (fuse 4.5x16mm)
- Ceramic tube with filling
- Safety clip: Bronze, tin-plated
- Soldering heat resistance (according to IEC60068): 260°C, 10s
- REACH Art. 33: Contains lead CAS# 7439-92-1
Technical specifications
- Housing material: Glass tube, with extinguishing agent filling
- Material: Nickel-plated brass connections
- Melting Integral: 5.2 A²/s.
- Rated breaking capacity 1,000 A.
- Voltage drop 130 mV
- Product type
Micro fuse
- Nominal voltage
250 V AC
- Dim
(Ø x H) 5 mm x 6.4 mm
- Nominal current - rounded value
4 A
- Nominal current
4.00 A
- Release characteristics
Time delay -T-
- Type
SMD
- Length
20 mm
- Width
7.4 mm
- Height
6.4 mm
- (Ø)
5 mm
- Content
1 pc(s)
- Type
160500.4GT
- Certification marks
IEC60127
- Weight
1.5 g
Documents & Downloads
Datasheet
Datasheet 3842403 SIBA 160500.4GT Micro fuse SMD 4.00 A 250 V AC Time delay -T- 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3842403 SIBA 160500.4GT Micro fuse SMD 4.00 A 250 V AC Time delay -T- 1 pc(s)
Description
Can be used when high and only slowly decreasing inrush currents occur
